Taw qhia
Qhov no tsis siv neeg tooj liab yeeb nkab brazing vuam tshuab txais cov nplaim (oxygen-propane nplaim) tsis siv neeg hlau pub mos brazing tooj liab raj txheej txheem. Lub tog raj kheej tig tau txais thiab lub raj tooj liab yog txiav ua tiav. Cov khoom siv brazing siv Φ4mm tin-based brazing khoom nrog brazing flux. Lub stainless hlau sab nraud lub tog raj kheej thiab tooj liab raj yog rhuab los ntawm nplaim taws kom ncav cuag lub melting kub ntawm cov khoom brazing. Lub brazing flux tshem tawm cov oxide nplai rau ntawm qhov chaw ntawm lub raj tooj liab thiab lub tog raj kheej, thiab paub qhov sib kis thiab ntub ntawm cov hlau molten hlau, yog li sau qhov sib txawv ntawm lub raj tooj liab thiab lub tog raj kheej kom tsim tau ib qho zoo nkauj fillet brazing seam. Txhawm rau tiv thaiv cov nplaim hluav taws kub kub los ntawm kev puas tsuaj rau cov khoom siv ntawm lub cev stainless hlau thiab vuam deformation, lub tshuab dej txias yog muab los ua kom txias cov khoom ua haujlwm thaum lub sij hawm brazing, yog li ua kom lub brazing zoo ntawm lub tog raj kheej sab nraud thiab qhov zoo. deformation ntawm lub workpiece.
Khoom siv configuration rooj
|
Tsis muaj. |
Yam khoom |
Technical parameters |
|
1 |
Qauv |
L-1400 |
|
2 |
Fais fab mov |
AC 220V / 380V, 50Hz |
|
3 |
Rated zog (Kw) |
4.5 |
|
4 |
Vuam Copper Tube Specifications (mm) |
φ9.5×1 |
|
5 |
Vuam Copper Tube Khoom |
TP2 |
|
6 |
Vuam lub tog raj kheej phaj Thickness (mm) |
3.0-4.0 |
|
7 |
Lub cev hnyav (Kg) |
Tsawg dua los yog sib npaug li 150 |
|
8 |
Vuam Lub tog raj kheej khoom |
|
|
9 |
Vuam Lub tog raj kheej Inner Diameter (mm) |
Φ500-Φ850 |
|
10 |
Vuam Lub tog raj kheej Length (mm) |
900-1400 |
|
11 |
Txoj kab uas hla (mm) |
Φ4.0 |
|
12 |
Lub tog raj kheej tig ceev (mm / min) |
50-1500 |
|
13 |
Vuam ceev (mm / min) |
100-1000 |
|
14 |
Hlau pub ceev (mm / min) |
300-2000 |
|
15 |
Vuam qhov nrug (mm) |
50-110 |
Khoom Paub meej
Khoom npe:
Cryogenic kua lub tog raj kheej tooj liab yeeb nkab Brazing Vuam Tshuab
Longitudinal Vuam Tshuab (MIG / TIG)
Ob lub taub hau Circumferential Vuam Tshuab (MIG / TIG)
Daim ntawv thov
QINENG welding tsuas yog ua tiav cov khoom siv vuam tshuab (TIG vuam, MAG vuam, MIG vuam, PAW vuam) thiab kev siv vuam vuam tshuab rau ntau lub hom phiaj, nrog rau cov cuab yeej tsim khoom.
Peb lub tshuab nitrogen cryogenic tank vuam yog siv los tsim cov roj liquefied roj thooj voos kheej kheej (LPG thooj voos kheej kheej), hluav taws tua hluav taws lub tog raj kheej, lub tog raj kheej tub yees, lub rhaub dej kub, Dewar tso tsheb hlau luam, lub tog raj kheej ua kua cryogenic, lub tog raj kheej LNG lub tog raj kheej, lub tog raj kheej siab, thiab lwm yam.
Cim npe nrov: Cryogenic kua lub tog raj kheej tooj liab yeeb nkab brazing vuam tshuab, Tuam Tshoj cryogenic kua lub tog raj kheej tooj liab yeeb nkab brazing vuam tshuab manufacturers, lwm tus neeg, Hoobkas
